Product Details

Low Profile
Energy Efficient
This 680™ Series spa immerses you in a classic hydrotherapy experience that will make you feel good long after you leave the water. A mix of open seating and full-body relief make this compact hot tub perfect for indoor spa settings, patios, and small spaces. However, the Alicia™ spa is not short on massage options. A semi-lounge seat delivers total body relief that will surely leave you feeling renewed, and two therapy seats face one another to foster conversation while your shoulders and back find relief.

Seating & Jets

Alicia Features

Bento card background

Plug and Play Model

Can be plugged into standard 120v outlet without additional electrical requirements.

Bento card background

Controls

Simplified LED control panel streamlines spa functions.

Bento card background

Lighting and Waterfalls

Standard lighting brightens up the interior and soothing waterfall adds ambiance.

Bento card background

Clean Water

CLEARRAY Active Oxygen™ technology and a 50 square foot vertical filter raises the bar on traditional filtration.

Specifications

Seats
3
Jets
21
Dimensions
69 x 80 x 33 IN
Dimensions (cm)
176 x 204 x 84 CM
Width
80 in
Height
33 in
Width (cm)
204 cm
Height (cm)
84 cm
Length (cm)
176 cm
Volume
210 gal
Volume (L)
795 L
Dry Weight
583 lb / 265 kg
Dry Weight (kg)
265 kg
Filled Weight
2334 lb
Filled Weight (kg)
1059 kg
Amperage
North America Convertible Model (60 Hz): 120 VAC@15A with Supplied GFCI Cord or 240 VAC@30A or 40A (Hard Wired Only); Export (50 Hz): 230-240 VAC@1x16A, 1x32A or 2 out of 3-phase (see manual); or Suitably Rated Circuit Breaker to Comply with Local Electrical Regulations. Certain Countries May Require 2 Power Inputs; Two GFCI/RCD Breakers are Required for This Configuration.
Primary Pump
North America (60 Hz): 2-Speed, 2.5 HP brake, 1.5 HP continuous, 48 Frame Export: (50 Hz): 2-Speed, 2.0 HP continuous
Circulation Pump
No
Water Management System
Factory installed ClearRay Active Oxygen® System
Filtration System
MicroClean® Mini™ Filter Cartridge System
Filter Type
75 ft² MicroClean® Mini™ Filter Cartridge System
Number of Filters
1
Diverter Valves
0

Frequently Asked Questions

View All FAQs

Not always. Seating capacity is based on the number of molded seat positions in the shell, but real-world comfort depends on a few factors. First, body size: larger adults need more legroom, and some seats are designed for average or smaller builds. Second, seat type: a lounge seat occupies footwell space that other seated users share; when the lounge is occupied, it can effectively reduce the usable space for everyone else. Third, jet positioning: some seats are designed with specific jet configurations for individual use. A practical rule of thumb: subtract one from the stated capacity to get the number of adults who can soak comfortably at the same time. When you visit a dealer showroom, sit in the actual model you're considering. Wet test sessions are available at many Sundance® dealers so you can evaluate fit and comfort before you commit.

There are a few things to line up before delivery day. First, your electrical: most Sundance® spas require a dedicated 240V/50-amp GFCI circuit installed by a licensed electrician. Some smaller models run on standard 120V, but confirm this with your dealer early, as electrical work can take time to schedule. Second, your foundation should be in place and fully cured before the spa arrives. On delivery day, the crew will need clear access from the street or driveway to your installation site, so measure any gates, fences, or doorways along that path in advance. Most spas are delivered on a pallet and moved with a dolly or crane. Once the spa is in place, your dealer's setup team will connect it and walk you through initial startup. You'll balance your water chemistry before the first soak. Your Quick Start Guide covers the steps, and your dealer is always available to help. Plan for about 24 hours for the water to heat to your preferred temperature before you climb in.

Start by measuring the area where you plan to put your spa . You'll need at least 2 feet of clearance on all sides for access and servicing. Also note any gates, doorways, or pathways the delivery team will need to pass through. Standard spa dimensions range from roughly 6'x6' for smaller 2-person models to 8'x8' or larger for 6-8 person spas. Swim spas would be even larger. Measure access points too because most spas need a clear path of at least 36 inches wide. Your Sundance® dealer can walk you through exact dimensions for any model you're considering.
